What Functions Does the Lingkai Cable Pulling Hand Tractor Combine in One Machine?

The Lingkai Cable Pulling Hand Tractor is built to handle pulling, lifting, and moving itself around a job site. Instead of bringing separate equipment for each task, one machine switches between functions as the work requires. It is adapted from the 12-type walking tractor, a chassis design known for durability. With a 15HP engine running at 2000 RPM and a four-speed gearbox, the tractor delivers different combinations of force and speed depending on the gear selected.

Pulling Function

How It Pulls
The tractor pulls by winding wire rope onto a drum. The engine drives the gearbox, the gearbox turns the drum, and the drum winds the rope. As the rope winds, it pulls whatever is attached at the other end. The traction force depends on which gear is selected. In first gear, pulling force reaches 60KN at 11.7 meters per minute. In fourth gear, pulling force drops to 12KN but speed rises to 55.6 meters per minute.

What It Pulls
The tractor is used to pull cables during tower erection and other construction work. It can also pull loads horizontally across the ground. The no-twist wire rope recommended for this machine keeps the load from spinning as it is pulled, which matters when the load is a cable bundle or a structural component that must maintain orientation.

Lifting Function

How It Lifts
The same drum and gearbox system that pulls horizontally also lifts vertically. The wire rope runs from the drum up to a pulley or lifting point, and the tractor winds the rope to raise the load. During tower erection, components often need to be raised into position before they are secured. The tractor lifts these components while the pulling function holds them in place or moves them laterally.

Seven Grooves Protect the Rope
The drum has seven grooves. The grooves guide the wire rope as it winds, keeping each wrap separated from the next. When rope wraps overlap, they press against each other and cause friction and wear. The grooved design prevents this overlap. The rope winds in an orderly pattern, reducing internal wear and extending the rope's service life. The grooved drum also makes the winding process smoother and reduces the chance of the rope snagging during operation.

Self-Propelled Movement

It Moves on Its Own Wheels
The tractor has wheels and a walking tractor chassis. It drives itself to the work position. There is no need for a truck or crane to relocate it. The operator starts the engine, selects a gear, and drives the machine to where the pulling or lifting is needed.

Travel Speed and Ground Clearance
The travel speed ranges from 3 to 13 kilometers per hour, depending on the gear selected. Ground clearance is 150mm, which allows the tractor to roll over uneven ground without getting stuck on small obstacles. The wheelbase is 1040mm. On tower erection projects, the work moves from one tower location to the next. A machine that can drive itself between locations saves the time and equipment required to load and unload it.

Four-Speed Gearbox

Two Forward and Two Reverse Gears
The gearbox has four gears total: two forward and two reverse. Each gear provides a different combination of traction force and speed. Lower gears produce more force at slower speeds. Higher gears produce less force at faster speeds. Reverse gears allow the tractor to back away from the load or reposition without turning around.

Matching Gear to Task
Heavy loads that require high pulling force use first or second gear. Light loads that need to move quickly use third or fourth gear. When pulling a cable that is already moving freely, fourth gear moves it quickly. When starting a heavy load from a standstill, first gear provides the force needed to overcome inertia. Reverse first gear provides 6.2 meters per minute, and reverse second gear provides 21.3 meters per minute.

Product Specifications

Contact Ningbo Lingkai for application support, maintenance services, or operation training for the Cable Pulling Hand Tractor.
